    IP30 Rated LED Lighting Rocker Switch Single Pole On Off Cordline Switch 303 250V 2A

    Ask Lasest Price
    Brand Name : AMPFORT
    Model Number : 303
    Certification : ENEC Ce CQC Kema
    Price : To Be Negotiated
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 500KKPCS Per month
    Delivery Time : 2 Weeks
    • Product Details
    • Company Profile

    IP30 Rated LED Lighting Rocker Switch Single Pole On Off Cordline Switch 303 250V 2A


    IP30 Rated LED Lighting Rocker Switch Single Pole On-off Cordline Switch 303 250V 2A


    Description Of The Cordline Switch 303


    The wire switch is used to control the on and off of the power supply. It can be wired as follows: Connect the live wire to the L terminal of the switch (live wire inlet), and connect the L1 terminal of the switch (live wire outlet) to the L of the two-hole socket Connect the terminal (live wire connection port), and connect the neutral wire to the N connection terminal (neutral wire connection port) of the socket.


    Features Of The Cordline Switch 303


    - Inline terminal connections
    - Double pole switching and through earth terminal
    - Suitable for table lamps and other small electrical appliances
    - The Ampfort cordline switch has double pole action with screw terminals and earth feed through screw terminal. The unit is designed for round 3 core flexible cords and provides cord grip at entry to reduce strain on terminal connections.


    Dimension Of The Cordline Switch 303



    Ordering Info Of The Cordline Switch 303



    Type 303 in line cord switch:(303-12)


    Item No.303-12
    Electrical Data
    IEC/EN
    Rated Voltage (V)250V (AC)
    Rated Current (A)2×2A
    Ambient TemperaturePolypropyleneT55
    PolycarbonateT55
    Connection Data
    IEC/EN
    Cross SectionFlexible cableH03VVH2-F 2x0.75mm² H05VVH2-F 2x0.75mm²
    Means of connectionclamped
    Number of terminalsUnipolar
    Protection Degree
    IP30
    Materials
    Insulation MaterialsDesignationPolypropylene, Polycarbonate
    Flammability classUL 94V-2
    Clamping UnitBrass
    Packing Quantity (pcs/carton)
    500

    Type 303 in line cord switch:(303-13)


    Item No.303-13
    Electrical Data
    IEC/EN
    Rated Voltage (V)250V (AC)
    Rated Current (A)2×2A
    Ambient TemperaturePolypropyleneT55
    PolycarbonateT55
    Connection Data
    IEC/EN
    Cross SectionFlexible cableH03VV-F 3G0.75mm² H05VV-F 3G0.75mm² ²
    Means of connectionclamped
    Number of terminalsUnipolar
    Protection Degree
    IP30
    Materials
    Insulation MaterialsDesignationPolypropylene, Polycarbonate
    Flammability classUL 94V-2
    Clamping UnitBrass
    Packing Quantity (pcs/carton)
    500

    Type 303 in line cord switch:(303-22)


    Item No.303-22
    Electrical Data
    IEC/EN
    Rated Voltage (V)250V (AC)
    Rated Current (A)2×2A
    Ambient TemperaturePolypropyleneT55
    PolycarbonateT55
    Connection Data
    IEC/EN
    Cross SectionFlexible cableH03VVH2-F 2x0.75mm² H05VVH2-F 2x0.75mm²
    Means of connectionclamped
    Number of terminalsBipolar
    Protection Degree
    IP30
    Materials
    Insulation MaterialsDesignationPolypropylene, Polycarbonate
    Flammability classUL 94V-2
    Clamping UnitBrass
    Packing Quantity (pcs/carton)
    500

    Type 303 in line cord switch:(303-23)


    Item No.303-23
    Electrical Data
    IEC/EN
    Rated Voltage (V)250V (AC)
    Rated Current (A)2×2A
    Ambient TemperaturePolypropyleneT55
    PolycarbonateT55
    Connection Data
    IEC/EN
    Cross SectionFlexible cableH03VV-F 3G0.75mm² H05VV-F 3G0.75mm² ²
    Means of connectionclamped
    Number of terminalsBipolar
    Protection Degree
    IP30
    Materials
    Insulation MaterialsDesignationPolypropylene, Polycarbonate
    Flammability classUL 94V-2
    Clamping UnitBrass
    Packing Quantity (pcs/carton)
    500

    Packing info


    500 pcs per carton, carton size: 50.8X32X22.5 cm, net weight: 5kg, gross weight: 6kg
