    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm

    Ask Lasest Price
    Brand Name : AMPFORT
    Model Number : 6F/R632F
    Certification : CUL,CUL,REACH,ROHS
    Price : 1~1.2 USD/PC
    Payment Terms : Telegraphic Transfer
    Supply Ability : 500,000,000PCS Per Month
    Delivery Time : 7 workdays
    • Product Details
    • Company Profile

    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm


    2-SMD Square End Block High Current Fast Acting SMD Ceramic Tube Fuse 6F 6x32mm

    Description Of The Ceramic Tube Fuse 6F 6x32mm

    Ampfort introduces Bussmann® series of high-current, fast-acting, surface-mount (SMD) fuses designed for the power requirements of the next generation telecommunications and computing systems. The compact footprint of the 6F series allows developers to utilize less circuit board space with a higher current rating, higher voltage rating, and improved performance. The increased current squared time (I2t) ratings in the 6F are ideal for power systems that are used in next generation server and desktop computers, gaming consoles, industrial and consumer electronics, storage systems, base stations, test equipment, and LED lighting.


    Features Of The Ceramic Tube Fuse 6F 6x32mm

    • Fast acting
    • Small size(32.0x6.8x6.8mm)
    • Wide range of current rating 0.1-100A available
    • -55°C to 125°C operating temperature range
    • Low temperature de-rating
    • Tape and Reel for automatic placement
    • Surface mount high current fuse
    • Fully compatible with lead-free solder alloys and higher temperature profiles associated with lead-free assembly
    • Standards:In accordance with UL 248-14.
    • High melting i2t
    • Enhanced thermal cycling endurance
    • Higher I2 t than the leading competitors in the same package, allowing for higher inrush currents and fewer nuisance openings
    • Highest available current rating in a traditional SMD fuse
    • Operating temperature of -55 °C to +125 °C ensuring protection in harsh climates


    Main Specification Of The Ceramic Tube Fuse 6F 6x32mm

    CategoryCircuit Protection Fuses
    MfrAMPFORT
    Series6F
    PackageTape & Reel (TR)
    Mounting TypeSurface Mount
    Fuse TypeBoard Mount (Cartridge Style Excluded)
    Response TimeFast blow
    Current Range0.1-100A
    Voltage range32V-700V
    Package / Case32.0x6.8x6.8mm
    Breaking Capacity @ Rated Voltage50KA
    Operating Temperature-55°C ~ 125°C
    ECCNEAR99
    HTSUS8536.10.0040



    Application Of The Ceramic Tube Fuse 6F 6x32mm

    * Primary and secondary circuit protection:Server and desktop power supplies
    * Gaming console systems
    * Voltage regulator modules (VRM)
    * Storage system power
    * Primary and secondary circuit protection (continued):Base station power supplies
    * Basic power supplies
    * LED and general lighting
    * Test equipment
    * Server and desktop
    * Gaming console systems
    * Voltage Regulator Module (VRM)
    * Storage system power
    * Base station
    * Power supplies
    * LED lighting
    * Test equipment


    Selection Table Of The Ceramic Tube Fuse 6F 6x32mm

    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm


    Certifications Of The Ceramic Tube Fuse 6F 6x32mm

    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm


    Recommended products Of The Cartridge Fuse 5F

    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm
    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm




    Fuse Key Testing Instrument & Capability Of The Ceramic Tube Fuse 6F 6x32mm

    700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm700V Square End Block Ceramic Tube Fuse Fast Acting SMD 6x32mm


    Approvals Of The Ceramic Tube Fuse 6F 6x32mm

    UL ApprovalApproval from Underwriters Laboratories (UL) indicates that the fuse is manufactured in full compliance with the UL 248-14 standard. UL Recognition, c-UL Listing, c-UL Recognition, c-UL-us Listing, and c-UL-us Recognition do not imply full compliance with UL-248-14.
    CSA CertificationApproval from the Canadian Standards Association (CSA) indicates that the fuse or fuse holder is manufactured in full compliance with CSA C22.2, No. 248.14 or CSA C22.2, No. 39.
    BSI ApprovalBritish Standards Institute (BSI) approval indicates that the fuse is manufactured in full compliance with the appropriate section of IEC 60127 (BS 4265).
    VDE ApprovalApproval from VDE, a German organization, indicates that the fuse or fuse holder is manufactured in full compliance with the appropriate section of the IEC 60127 standard.
    SEMKO ApprovalApproval from SEMKO, a Swedish organization, indicates that a fuse or fuse holder is manufactured in full compliance with the appropriate section of the IEC 60127 standard.
    CCC CertificateChina Compulsory Certification (CCC), The CCC certificate was introduced in 2002 and applies to imported goods as well as to Chinese products.
    PSE ApprovalThe Electrical Appliance and Material Safety Law applies to enterprises that manufacture or import products in Japan
    TUV ApprovalTÜV (Technischer Uberwachungsverein) is of German origin, translated as the Technical Inspection Association. TÜV is the leading and the most competent provider of product testing and certifications for the worldwide marketplace. The certification ensures compliance with domestic and international guidelines, standards and directives.



    Fuse Terminology Of The Ceramic Tube Fuse 6F 6x32mm

    TermsDefinition
    Rate/working currentCurrent rating is the normal operating current of the fuse. The maximum continuous operating current of the circuit and the influence of the ambient temperature (Normally is 25 C) are important considerations when specifying the current rate.
    Maximum currentIt is related to the inrush current for various circuits, when we select a correct fuse, we need to consider this and choose “fast-acting” or “Time delay”product.
    VoltageThe rated voltage is the maximum voltage at which a safe fault current interrupt occurs. The maximum effective operating voltage of the circuit is an important consideration when specifying the rated voltage. Also, consider AC or DC circuits. Higher voltages can be used in lower voltage circuits, but not vice versa.
    I.R. or Breaking CapacityThe rated breaking capacity or interrupt rating is the short-circuit current at which the fuse can blow (at the rated voltage) without destruction or the maintenance or arcing or damage the fuse case. The maximum possible fault current is an important consideration when specifying a rated breaking capacity.
    Size or TypeDepends on the requirements, normally it has SMD, Cartridge, radial leaded or various size in high voltage fuses.
    Short circuitOver 500% to 700% of rated – current applies to the fuse.
    OverloadingOver 100% rated-current apply to the fuse.
    Inrush currentInrush current, input surge current, or switch-on surge is the maximal instantaneous input current drawn by an electrical device when first turned on.
    TC curveTime – Current Curve. The fuse curves represent the cutoff value of the prospective available short-circuits current under the given circuit.
