    ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600

    Ask Lasest Price
    Brand Name : AMPFORT
    Model Number : CWF 4
    Certification : ROHS
    Price : 1 US$/PC
    Payment Terms : T/T, Western Union
    Supply Ability : 1,000,000PCS PER WEEK
    Delivery Time : 10 workdays
    • Product Details
    • Company Profile

    ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600


    Customized Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600


    Description Of The Automatic Transmission Oil Temperature Sensor


    The Transmission Oil Temperature Sensor is used in automotive applications to monitor the temperature of transmission fluid and provide feedback to prevent overheating of the transmission, which can cause performance and reliability issues.


    Application description --Suitable for temperature control module in gearbox;
    Assembly method -- Bolt connection.


    APPLICATIONS Of The Automatic Transmission Oil Temperature Sensor


    * Automotive Transmission Oil Temperature Sensing
    * Fluid Temperature Sensing


    Specification Of The Automatic Transmission Oil Temperature Sensor


    NameNTC Temperature Sensor
    BrandAMPFORT
    ModelCWF 4
    UseAutomatic Transmission Oil
    TerminalRing lug
    Terminal MaterialNickel Plated Brass
    R250.2~2000k Ohm
    Beta3100~4500
    Accuracy1%
    SizeCustomized

    Series Data Of The Automatic Transmission Oil Temperature Sensor


    ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600


    Certifications Of The Automatic Transmission Oil Temperature Sensor


    ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600ROHS Nickel Plated Brass Automatic Transmission Oil Temperature Sensor 5k 3600


    What are the symptoms of a broken gearbox oil temperature sensor?


    The symptoms of a broken gearbox oil temperature sensor are:

    1. Start frustration;

    2, 2 and 3 gears impact, reverse gear delay;

    3. Abnormal noise, transmission failure alarm.


    The transmission oil temperature sensor is installed on the valve plate in the oil pan of the automatic transmission, and is used to detect the temperature of the hydraulic oil of the automatic transmission as the basis for the electronic control unit to perform shift control, oil pressure control and lock-up clutch control. Inside the transmission oil temperature sensor is a negative temperature coefficient semiconductor thermistor. The higher the temperature, the lower the resistance. The characteristic curve of its resistance changing with temperature changes can be seen in the characteristics of the negative temperature coefficient thermistor in the coolant temperature sensor. The computer detects the temperature of the hydraulic oil of the automatic transmission according to the change of its resistance.


    Where is the oil temperature sensor of the gearbox?


    The location of the gearbox oil temperature sensor is: the valve plate in the automatic transmission oil pan. It is used to detect the temperature of the hydraulic oil of the automatic transmission and act as an electronic control unit for shift control, oil pressure control and lock. Inside the transmission oil temperature sensor is a negative temperature coefficient semiconductor thermistor. The higher the temperature, the lower the resistance. The characteristic curve of its resistance changing with temperature changes can be seen in the characteristics of the negative temperature coefficient thermistor in the coolant temperature sensor. The computer detects the temperature of the hydraulic oil of the automatic transmission according to the change of its resistance. The phenomenon that the gearbox oil temperature sensor is broken includes: automatic de-gearing, disorderly gearing, fault code report, display of oil temperature is too high, so when this problem occurs, it should be overhauled in time.
