    19mm ATC 80V PCB Mount Fuse Holder 178.6152.0001 30 Amp Panel Mount Fuse Holder

    Ask Lasest Price
    Brand Name : AMPFORT Or Littelfuse
    Model Number : 178.6152.0001
    Certification : ROHS
    Price : Negotiable
    Payment Terms : T/T,Paypal, Western Union
    Supply Ability : 10,000,000 Pieces Per Month
    Delivery Time : 7-10 Workdays
    • Product Details
    • Company Profile

    19mm ATC 80V PCB Mount Fuse Holder 178.6152.0001 30 Amp Panel Mount Fuse Holder


    19mm ATC ATO FKS 287 Stackable Automotive Blade Fuse Holder 178.6152.0001 80V


    Description Of The Automotive Blade Fuse Holder 178.6152.0001 80V


    1) Fuseholder for ATO/ FKS size fuses-links. Attachable in X - direction. Rated voltage 80V; crimp terminals.

    2) Fuse holders for FKS blade fuses series FKH, type Littelfuse/Pudenz 178.61.

    3) With tab terminals; Connection material: tinned copper alloy. Housing and adapter: thermoplastic. Rated current: max. 30 A. Rated voltage: max. 80 V. Fuse holder retainers are available on separate order. Two parts are required for the retainer: snap-on lock on the right, and without lock on the left (please order each item separately).

    4) In-line single fuse holder for standard blade fuses. These holders can be clipped together to form a multi-fuse block. Connections are made via male blade terminals mounted on the sides.
    5) Optional fixing plate available to secure the fuse holder to a flat surface (see further information).
    6) Accepts our range of standard blade fuses (including LED glow versions).
    7) Fixing plate for standard blade fuse holder


    Features Of The Automotive Blade Fuse Holders.


    • For Mini, Low Profile, Standard and Maxi Blade Fuses.
    • PCB Mountable for Reliable Connection and Security.
    • Pre-Assembled for easy mounting and soldering to the PCB.
    • Mini sizes are compatible with Littelfuse ATO 297 series and Bussman ATM series automotive blade fuses.
    • Suitable for up to 20AMP applications.
    • Mini Low Profile sizes are compatible with Littelfuse 0891 series and Bussman Low Profile ATM series automotive blade fuses.
    • Suitable for up to 20AMP applications.
    • Standard sizes are compatible with Littelfuse ATO 257 series and Bussman ATC series automotive blade fuses.
    • Suitable for up to 30AMP applications.
    • Maxi sizes are compatible with Littelfuse MAXI series and Bussman MAX series automotive blade fuses.
    • Suitable for up to 40AMP applications.
    • 2 in 1 fuse holder is also available to accomodate both Standard and Low Profile Mini style Automotive Blade Fuses in Thru-Hole Mount fuse holder


    Dimension Of The Automotive Blade Fuse Holder 178.6152.0001 80V (mm)



    Main Specification Of The Automotive Blade Fuse Holder 178.6152.0001 80V


    CategoriesCircuit Protection
    Fuseholders
    ManufacturerLittelfuse Inc.
    SeriesFKH/ATO/ATC Standard
    PackagingBulk
    Part StatusActive
    Mounting TypeChassis Mount
    Fuse Size0.75" L x 0.2" W (19.1mm x 5.1mm)
    For Use With/Related ProductsATC, ATO,287
    Fuse TypeBlade
    Fuseholder TypeHolder
    Number of Circuits1
    Voltage80V
    Housing + AdapterOut of thermoplastic (UL 94-V0, heat-resistant)
    Termination StyleCrimp
    Contact MaterialCopper Alloy
    Contact FinishTin
    ConnectionsLeaf spring connector systems, soldering terminals, copper alloy, tinned
    ColorBlack
    Type of fuse accessoriesfuse holder
    Fuse size19mm
    Mountingon cable
    Fuses applicationautomotive fuses
    Operating temperaturemax. 130°C


    More Automotive Blade Fuse Holder 178.6152.0001 80V
